What Is an MTB Top Cap?
The top cap (also called a stem cap, headset cap or a Hexcap) is the small cap that sits at the very top of your bike's fork steerer tube. It's secured by a single bolt — the top cap bolt — and its primary job is to preload your headset bearings, keeping your steering smooth and play-free.
But for riders who care about the details, the top cap is also one of the easiest and most affordable ways to personalise your build. A quality top cap from HEXCAPS turns a functional component into a statement piece, without hurting your wallet too hard. (A Drippy Donut Hexcap is pictured below)

What Does a Top Cap Actually Do?
- Preloads the headset: The bolt tensions the headset bearings so there's no rattle or play in your steering.
- Seals the steerer tube: Keeps dirt, water, and debris out of the top of your fork.
- Expresses your style: It's the first thing people see when they look at your cockpit, make it count.
How to Choose the Right Size
Most modern mountain bikes use a 1-1/8" (28.6mm) steerer tube, which is the standard for threaded and threadless headsets alike. This means the vast majority of aftermarket top caps — including all HEXCAPS designs, will fit your bike straight out of the packet.
Before you buy, just confirm:
- Your steerer tube diameter (check your fork specs or measure the outside of the steerer — 1-1/8" is almost universal on MTB).
- Your top cap bolt thread size — M6 is standard. Our Black Bolt top cap bolt is compatible with all HEXCAPS designs.
If you're running a tapered steerer (1.5" at the bottom, 1-1/8" at the top), the top cap size is still 1-1/8" — so you're good.
What Features Should You Look For?
Material & Durability
Look for top caps machined from aluminium alloy. These materials handle trail vibration, UV exposure, and the occasional crash without cracking or fading. Topcaps are also not meant to be tightened hard, 1-2NM is perfect (Tighten till theres some resistance). Many topcaps can snap if over loaded, given their job of compression, they have been made to not be under high tension. If you end up snapping one of our caps, email us and we can help you get a new one. (Hexcapsbusiness@gmail.com)
Bolt Compatibility
A top cap is only as good as the bolt holding it in place. Make sure your bolt is the right length for your steerer tube stack height. Our Black Bolt top cap bolt is designed to pair perfectly with any HEXCAPS design — no guesswork required. Also, every cap comes with a free bolt!
How to Install a Top Cap
Installing a top cap takes about two minutes and requires only a hex key (Allen key):
- Remove your old top cap bolt and cap, undo the pinch bolts of your stem before undoing the Topcap.
- Place the new top cap over the steerer tube.
- Thread in the bolt by hand first, then tighten with a 5mm hex key.
- Important: Do not overtighten. Snug is enough — you're preloading bearings, not clamping a wheel. Then lock everything in place by tightening your stem bolts.
- Check for headset play by squeezing the front brake and rocking the bike forward — there should be no clunking. If there is, repeat process. If theres still clunking, see your nearest bike shop.
- COMMON ISSUES: Not enough headset spacers, this can happen when the topcap is clamping straight onto the fork steerer, and there is not enough room for the topcap to compress, leaving your headset loose. Grab some of our Spacers to solve this. (See a bike shop if unsure)
How to Maintain Your MTB Top Cap
Top caps are low-maintenance, but a little care goes a long way:
- Check the bolt tension periodically — especially after rough rides or crashes. Vibration can loosen it over time.
- Inspect for cracks — if your cap takes a hard hit, check it before your next ride. A cracked cap won't preload your headset correctly.
- Re-torque after washing — if you pressure-wash your bike, re-check the top cap bolt before heading out.
Frequently Asked Questions
Are all MTB top caps the same size?
Almost. The 1-1/8" standard covers the vast majority of modern mountain bikes. If you're unsure, check your fork manufacturer's specs or measure your steerer tube diameter.
Can I use any bolt with my top cap?
I see alot of people running large bolts that eat into the top of our caps, and cause peeling of our design caps, please ensure you use provided bolt as this will ensure full topcap life. We recommend pairing your HEXCAPS top cap with our bolts for a guaranteed fit.
How tight should a top cap bolt be?
Finger-tight plus about a quarter turn with a hex key is usually enough. The goal is to remove headset play — not to clamp the cap down hard. Over-tightening can damage your fork's star nut or compression plug.
Will a top cap affect my bike's performance?
Only if it's incorrectly installed. A properly fitted top cap keeps your headset running smoothly. Beyond that, it's pure style — and style matters on the trail.
Ready to Upgrade?
Browse the full HEXCAPS range and find a top cap that matches your ride. With designs dropping regularly and limited editions selling out fast, there's never been a better time to ditch the stock cap and ride with character.
